Orbital Motor OMM12.5 - 151G0034

Product Code:
151G0034
  • OMM 12.5 Low Speed High Torque motor, Geometric Displacement 12.9 cm³
  • Manufacturer : Danfoss

Read moreShow less
Manufacturer:
SGD$359.63 (tax excl.)
Last items in stock 2 Items
More Info

Specifications
Suitable for applications where high speed is required more than the torque, like sweepers or underwater hull cleaning
Cylindrical output shaft 5/8" with 9/16-18UNF side ports
Parallel key 3/16 x 3/16 x 3/4" B.S.46 682L8031

Accessories (not included):
1. Mounting Flange 151G0211
2. Seal Kit 151G0202

Read moreShow less
Data Sheet
151G0034

Data sheet

Unit weight
2.0kg
Packing size
10 x 10 x 20 cm
Maximum Continuous Output Speed
1550 rpm
Maximum Intermittent Output Speed
1940 rpm
Maximum Continuous Output Torque
16Nm
Maximum Intermittent Output Torque
23Nm
