Orbital Motor OMM20 - 151G0002

Product Code: 151G0002

OMM 20 Low Speed High Torque motor, Geometric Displacement 19.9 cm³

SGD$ 284.14

Suitable for applications where high speed is required more than the torque, like sweepers or underwater hull cleaning
Cylindrical output shaft 16mm with 3/8 BSP end ports
Parallel key A5 x 5 x 16 DIN 6885 682L8026

Accessories (not included):
1. Mounting Flange 151G0211
2. Seal Kit 151G0202

Unit weight	2.1 kg
Packing size	10 x 10 x 20 cm
Maximum Continuous Output Speed	1000 rpm
Maximum Intermittent Output Speed	1250 rpm
Maximum Continuous Output Torque	25Nm
Maximum Intermittent Output Torque	35Nm

OMM20 - 151G0002 (Drawing)

Download (147.02k)

OMM20 - 151G0002 (Selection)

Download (27.58k)

OMM20 - 151G0002 (Data)

Download (26.81k)
