Established in 2013, PV Global is the sales partner & appointed Authorised Service Centre (ASC) for Danfoss Power Solution’s (DPS) range of Open Circuit Hydraulics products.
OMSS 250 Low Speed High Torque motor, Geometric Displacement 250.0 cm3
This product is no longer in stock
Warning: Last items in stock!
OMS, OMT, and OMV are suitable for continuous operation under rough operating conditions: e.g. high pressure, thin oil, or frequent reversals. The tapered roller bearings on the output shaft make the motors suitable for absorbing static and dynamic radial loads. Besides the separately driven and hydraulically balanced disc valve, hydraulic and mechanical losses are reduced to a minimum. This gives the motors high efficiency - even at high pressures, and good starting characteristics.
If the application requires very smooth running at low speeds the choice of OMS, OMT, OMV or TMT is recommended
No output shaft with 1/2 BSP port
|Packing size||40 x 17 x 16 cm|
|Maximum Continuous Output Speed||300 rpm|
|Maximum Intermittent Output Speed||360 rpm|
|Maximum Continuous Output Torque||720Nm|
|Maximum Intermittent Output Torque||870Nm|
