Established in 2013, PV Global is the sales partner & appointed Authorised Service Centre (ASC) for Danfoss Power Solution’s (DPS) range of Open Circuit Hydraulics products.
This product is no longer in stock
Warning: Last items in stock!
Series 45 Frame E pumps have a single servo piston design with a cradle-type swashplate set in polymercoated journal bearings. A bias spring and internal forces increase swashplate angle. The servo piston decreases swashplate angle. Nine reciprocating pistons displace fluid from the pump inlet to the pump outlet as the cylinder block rotates on the pump input shaft. The block spring holds the piston slippers to the swashplate via the slipper retainer. The cylinder block rides on a bi-metal valve plate optimized for high volumetric efficiency and low noise. Tapered roller bearings support the input shaft and a viton lipseal protects against shaft leaks.
Typical applications include fan drives, HPU (Hydraulics Power Unit), mining equipment, drilling machines, lorry mounted cranes etc
|Unit weight||54 kg|
