Orbital Motor OMP X 100 - 11186730

Product Code:
11186730

OMP X 100 Low Speed High Torque motor, Geometric Displacement 99.8 cm3

Read moreShow less
Manufacturer:
SGD$383.15 (tax excl.)
More Info

The rollers in the gear rim reduce local stress, spread the tooth load over their projected area and reduce the tangential reaction forces on the inner gear reducing friction to a minimum. This gives long operating life and better efficiency even at continuous high pressures. Gearwheel sets with rollers are recommended for operation with thin oil and for applications having continually reversing loads. Some of the common medium duty applications include auger/winch/conveyor drive with planetary gearbox, sweeper brush, slewing application for crane, small road-roller propel, etc
Cylindrical output shaft 1 inch with 1/2 BSP side ports
Parallel key 1/4 x 1/4 x 1-1/4 BS46 682L8036

Accessories (not included):
1. Seal Kit 11188319

Read moreShow less
Data Sheet
11186730

Data sheet

Unit weight
7.0kg
Packing size
29 x 14 x 11 cm
Maximum Continuous Output Speed
615 rpm
Maximum Intermittent Output Speed
770 rpm
Maximum Continuous Output Torque
210Nm
Maximum Intermittent Output Torque
260Nm

Orbital Motor OMP X 100 -...

SGD$383.15
