Orbital Motor OMR x 315 - 11186652

11186652

OMR X 315 Low Speed High Torque motor, Geometric Displacement 310.1 cm3

SGD$ 519.07

Qty

The rollers in the gear rim reduce local stress, spread the tooth load over their projected area and reduce the tangential reaction forces on the inner gear reducing friction to a minimum. This gives long operating life and better efficiency even at continuous high pressures. Gearwheel sets with rollers are recommended for operation with thin oil and for applications having continually reversing loads. Some of the common medium duty applications include auger/winch/conveyor drive with planetary gearbox, sweeper brush, slewing application for crane, small road-roller propel, etc
Cylindrical output shaft 25mm with 1/2 BSP side ports
Parallel key A8 x 7 x 32 DIN 6885 682L8035

Accessories (not included):
1. Seal Kit 11188319

Unit weight 9.0kg
Packing size 29 x 14 x 11 cm
Maximum Continuous Output Speed 195 rpm
Maximum Intermittent Output Speed 245 rpm
Maximum Continuous Output Torque 340Nm
Maximum Intermittent Output Torque 450Nm
