JS120 joysticks are single axis, finger tip control devices. A single track potentiometer sensor measures handle position. The nominal output signal range is 10% to 90% of the joystick supply voltage. JS120 joystick are available in two mechanical style: Spring return to center and spring return to end.
Electronic ram generator, EHR controls the acceleration and deceleration times for flow from proportional valve ports A and B
EHR contains four potentiometers for the setting of ramp times. The setting of positive ramps, are made with A+ and B+ potentiometers for A and B ports respectively, while negative ramps, are set with A− and B− potentiometers....
Danfoss electronic flow regulation EHF is for use where the requirement is individual reduction of the flow from the two ports of the proportional valve. The flow can be reduced individually for ports A/B
There are two built-in potentiometers per function. Independently of each other, these will limit the signal voltage and thereby the flow from ports...
Mounting Base EHB, 11 pole, for EH modules
EHB can be mounted using two screws & can also be clipped onto DIN rails (DIN 46277). it is designed to be wired and contains self-lifting terminals & cross/slotted screws.
